Aruba 6100 12-Port PoE+ Gigabit Network Switch, 68 Gb/s Capacity, 45.1 Mpps Forwarding, 2 x 10G SFP+, 2 x Gigabit SFP, USB Type-C/A | JL679A


  • Feature: Details
  • : 1 x USB-A
  • Layer Services Supported: Layer 2 Support
  • Supported Protocols: SNMPv1, SNMPv2c, SNMPv3

3,727.92 د.إ

Aruba 6100 12G Class4 PoE 2G/2SFP+ 139W Switch The HPE Aruba Networking CX 6100 Switch Series is a modern family of entry-level access switches ideal for branch offices, mid-market enterprise, and SMB networks. Designed for reliable, simple, and secure access, the HPE CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile, and cloud applications. Prepare your network for tomorrow’s unpredictable demands with a powerful Aruba ASIC architecture and programmable AOS-CX operating system used across the HPE Aruba CX portfolio to deliver a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high-speed uplinks with up to 740W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12-port model is ideal for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the HPE CX 6100 also simplifies ownership with no switch software licensing requirements.

Technical Specifications

Feature Details
1 x USB-A
Layer Services Supported Layer 2 Support
Supported Protocols SNMPv1, SNMPv2c, SNMPv3
MAC Address Table Size 8K
Multicast Groups 512
SNMP Support 1, 2c, 3
Supported IEEE Standards 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3x
Latency 2.3 to 2.6 µs
Forwarding Rate 45.1 Mpps
Switching Bandwidth 68 Gb/s
Packet Buffer 12.38 MB
Flash Memory 16 GB
CPU Up to 1016 MHz Cortex A9 Dual-Core
Memory 4 GB DDR3
Power Draw 170.00 W (Max), 16.00 W (Idle)
AC Input Power 100 to 240 VAC, 50 / 60 Hz at 0.9 to 1.8 A
PoE Power Budget 139 W
PoE per Port 30 W
Power Supply Type Internal
Operating Temperature 32 to 113°F / 0 to 45°C
Operating Humidity 15 to 95% (Non-Condensing)
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 15 to 90% (Non-Condensing)
Cooling System Passive
Rack Form Factor 1 RU
