Intel Core i7-14700 2.1GHz LGA1700 Desktop Processor, 20 Core & 28 Threads, 5.4 GHz Max Turbo Boost, 33MB Cache, Integrated Intel UHD Graphics 770, 2CH DDR5 Memory / 192GB Max | BX8071514700SRN40


  • Total Cores: 20
  • # of Performance-cores: 8
  • # of Efficient-cores: 12
  • Total Threads: 28

1,279.34 د.إ

Intel Core i7-14700 Power up your productivity, gaming, and content creation with the Intel Core i7-14700 2.1 GHz 20-Core LGA 1700 Processor. Built with the Intel 7 process, this 14th generation desktop processor delivers improved power efficiency with a total of 20 cores while fitting the LGA 1700 socket. Featuring an optimized hybrid core architecture, the Core i7-14700 powers demanding applications and games with eight 2.1 GHz performance cores, while the 12 low-voltage efficient cores handle background tasks for smooth multitasking. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time. Features 20 Cores and 28 Threads 2.1 GHz Base P-Core Clock Speed 5.4 GHz Maximum Turbo Boost Frequency LGA 1700 Socket 33MB of cache memory Dual-Channel DDR5-5600 ECC Memory Integrated Intel UHD 770 Grap

SKU: SKU-C94EC8F1 Category: Brand:

Technical Specifications

Total Cores 20
# of Performance-cores 8
# of Efficient-cores 12
Total Threads 28
Max Turbo Frequency 5.4 GHz
Turbo Boost Max Technology 3.0 Frequency 5.4 GHz
Performance-core Max Turbo Frequency 5.3 GHz
Efficient-core Max Turbo Frequency 4.2 GHz
Performance-core Base Frequency 2.1 GHz
Efficient-core Base Frequency 1.5 GHz
Cache 33 MB Intel Smart Cache
Total L2 Cache 28 MB
Processor Base Power 65 W
Maximum Turbo Power 219 W
Marketing Status Launched
Launch Date Q1'24
Embedded Options Available Yes
Max Memory Size (dependent on memory type) 192 GB
Memory Types Up to DDR5 5600 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth 89.6 GB/s
ECC Memory Supported Yes
GPU Name Intel UHD Graphics 770
Graphics Base Frequency 300 GHz
Graphics Max Dynamic Frequency 1.6 GHz
Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units 32
Max Resolution (HDMI) 4096 x 2160 @ 60Hz
Max Resolution (DP) 7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel) 5120 x 3200 @ 120Hz
DirectX Support 12
OpenGL Support 4.5
OpenCL Support 3.0
Multi-Format Codec Engines 2
Intel Quick Sync Video Yes
Intel Clear Video HD Technology Yes
# of Displays Supported 4
Device ID 0xA780
DMI Revision 4.0
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations Up to 1×16+4, 2×8+4
Max # of PCI Express Lanes 20
Sockets Supported FCLGA1700
Max CPU Configuration 1
Thermal Solution Specification PCG 2020C
TJUNCTION 100°C
Package Size 45.0 mm x 37.5 mm
Intel Gaussian & Neural Accelerator 3.0
Intel Thread Director Yes
Intel Deep Learning Boost (Intel DL Boost) Yes
Intel Speed Shift Technology Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel Turbo Boost Technology 2.0
Intel Hyper-Threading Technology Yes
Intel 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States Yes
Enhanced Intel SpeedStep Technology Yes
Thermal Monitoring Technologies Yes
Intel Volume Management Device (VMD) Yes
Intel Standard Manageability (ISM) Yes
Intel Control-Flow Enforcement Technology Yes
Intel AES New Instructions Yes
Secure Key Yes
Intel OS Guard Yes
Execute Disable Bit Yes
Intel Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel VT-x with Extended Page Tables (EPT) Yes
