J5create 4K Game Capture Station, USB-C 3.2 Female Host Connector, HDMI Input Output, 3.5mm AUX Input Output, Up to 4K@30 Capture + 4K@60 Passthrough, 60W via USB-C PD, Black | JVA14

  • Audio Input: 1 – 3.5mm AUX
  • Audio Output: 1 – 3.5mm AUX
  • Audio Switcher: N/A
  • Host Connector: 1 – USB-C® 3.2 Female

464.91 د.إ

4K Game Capture Station 4K@30 Capture + 4K@60 Passthrough The JVA14 4K Game Capture Station is a capture device designed to stream and record your gameplay. It supports 4K @ 30 FPS video capture with 4K @ 60 FPS passthrough for consoles capable of 4K resolution. It has a 3.5 mm Audio In port and Mic In port allowing a headset to be connected for live commentary streaming on PlayStation™ 4 / 5, Xbox™ Series X / S, Xbox™ One X / S. It is fully compatible with OBS™ and other video streaming software, making it perfect for live streaming. The JVA14 is plug-and-play and compatible with macOS® and Windows® laptops and desktops. Specifications Audio Input 1

SKU: SKU-F3B90149 Category: Brand:

Technical Specifications

Audio Input 1 – 3.5mm AUX
Audio Output 1 – 3.5mm AUX
Audio Switcher N/A
Host Connector 1 – USB-C® 3.2 Female
Ports 1 – USB-C® 3.2 Gen 1
Power Source Bus-powered
Video Input 1 – HDMI™ Female
Video Output 1 – HDMI™ Female
Video Switcher N/A
Audio Channel 2.1 via HDMI™
Audio Frequency 48 kHz
Format USB™ 3.0: RGB / YUV4:2:2 / YUV4:2:0
Hdr Supported Yes
Headset 2.1 Stereo
Maximum Capture Capability USB™ 3.0: 3840 x 2160 @ 30
Maximum Capture Refresh Rate 4K30 FPS, 2K60 FPS, 1080p120 FPS
Maximum Capture Resolution 3840 x 2160
Maximum Passthrough Resolution 3840 x 2160
Max Passthrough Refresh Rate 4K60 Hz HDR, 2K144 Hz HDR, 1080p240 Hz HDR
Microphone Stereo microphone supported
Power Consumption ≤900 mA
Power Delivery 60W via USB-C®
Cable Length 3.3 ft (1m)
Color Black
Enclosure Type Aluminum
Operating Humidity <80% non-condensing
Operating Temperature 32 to 104°F (0 to 40°C)
Product Depth 0.7 in. (18.4 mm)
Product Height 2.5 in. (63.7 mm)
Product Weight 5.03 oz (142.5g)
Product Width 5.3 in. (134.6 mm)
Storage Humidity <85% non-condensing
Storage Temperature 14 to 149°F (-10 to 65°C)
