Noctua NF-A14X25r G2 PWM Case Fan, 140mm x 140mm Fan Size, 1500 RPM Fan Speed, 91.58 CFM Fan Airflow, SSO2 Bearing, Sterrox LCP Material, Brown | NF-A14X25r G2 PWM


  • Size: 140x140x25 mm
  • Mounting Hole Spacing: 105×105 mm
  • Connector & Pin-Configuration: 4-pin PWM
  • Cable Length: 20 cm + 30 cm NA-EC1 extension cable

148.06 د.إ

NF-A14X25r G2 PWM Succeeding the award-winning NF-A15 and building on the technological innovations of the ground-breaking NF-A12x25, the NF-A14x25r G2 is Noctua’s next-generation round-frame 140mm flagship model: Made from Sterrox® LCP, its highly optimised Progressive-Bend impeller with winglets, Flow Acceleration Channels and Centrifugal Turbulator hub combined with a tip-clearance of only 0.7mm allow the NF-A14x25r G2 to further improve its predecessor’s renowned quiet cooling performance. This makes it not only a perfect fit for Noctua’s next-generation 140mm class heatsinks but also an excellent upgrade for existing cooler models such as the NH-D15(S) or NH-U14S series (Sx2-PP set recommended for push/pull configurations). The 4-pin PWM version supports fully automatic speed control via PWM fan headers and comes with a Low-Noise Adaptor to reduce the maximum speed from 1500 to 1250rpm. Its ultra low-loss etaPERF™ motor with Smooth Commutation Drive 2 technology doesn’t only provide unprecedented energy efficiency and running smoothness but thanks to the new SupraTorque™ feature, it can also leverage extra torque headroom to keep the fan at its desired speed when working against back pressure, thereby ensuring even better performance on heatsinks. Topped off with Noctua&rsqu

SKU: SKU-C6E93189 Category: Brand:

Technical Specifications

Size 140x140x25 mm
Mounting Hole Spacing 105×105 mm
Connector & Pin-Configuration 4-pin PWM
Cable Length 20 cm + 30 cm NA-EC1 extension cable
Bearing SSO2
Blade Geometry Progressive-Bend impeller
Frame Technology AAO (Advanced Acoustic Optimisation)
Material Sterrox® LCP
Rotational Speed (+/- 10%) 1500 RPM
Rotational Speed with L.N.A. (+/- 10%) 1250 RPM
Airflow 155.6 m³/h
Airflow with L.N.A. 127.1 m³/h
Acoustical Noise 24.8 dB(A)
Acoustical Noise with L.N.A. 19.7 dB(A)
Static Pressure 2.56 mm H₂O
Static Pressure with L.N.A. 1.3 mm H₂O
Input Power (Max.) 2.28 W
Max. Input Current 0.19 A
Operating Voltage 12 V
Voltage PWM Signal 5 V
MTTF > 150,000 h
Included Accessories NA-RC16 Low-Noise Adaptor (L.N.A.), NA-YC1 4-pin PWM splitter cable, NA-EC1 30 cm extension cable, 4x NA-AV2 anti-vibration mounts, fan screws
