Crystal UHD Signage QMC Introducing QMC, the slimmest display in the Samsung UHD Signage. It brings elegance to business while maximizing space. Its enhanced internal solutions and intuitive home screen UX make it easy to use. Businesses in various verticals can achieve growth with QMC’s efficiency and design innovation. Key Features Ultra Slim Depth Even Bezel Centered VESA Holes Specifications Display Diagonal Size
Digital Signage
Samsung Crystal Signage QMC, 65″ 4K UHD VA Display, 75Hz Refresh Rate, 8ms Response Time, 11.5 mm Bezel Width, Tizen 7.0 OS, 16GB Flash Memory, 400 x 300mm VESA Mount, Black | LH65QMCEBGCXUE
- Diagonal Size: 65"
- Panel Type: VA
- Resolution: 3,840 x 2,160
- Pixel Pitch (HxV, mm): 0.372×0.372mm
3,431.94 د.إ
Technical Specifications
| Diagonal Size | 65" |
| Panel Type | VA |
| Resolution | 3,840 x 2,160 |
| Pixel Pitch (HxV, mm) | 0.372×0.372mm |
| Brightness (Typ) | 500 nit |
| Contrast Ratio | 4,000:1 |
| Viewing Angle (H/V) | 178/178 |
| Response Time | 8ms |
| Color Gamut | 72% (NTSC) |
| Glass Haze | 25 % |
| H-Scanning Frequency | 30~81kHz |
| Maximum Pixel Frequency | 594MHz |
| V-Scanning Frequency | 48~75Hz |
| Contrast Ratio (Dynamic) | Mega |
| Operation Time Support | 24/7 |
| HDMI In | 3 |
| DP In | 1 |
| Version of HDMI | 2 |
| Version of DP | 1.2 |
| Version of HDCP | 2.2 |
| USB | 2 |
| IR In | Yes |
| Audio In | No |
| Audio Out | Stereo Mini Jack |
| RS232 In | Yes |
| RS232 Out | Yes |
| RJ45 In | Yes |
| WiFi | Yes |
| Bluetooth | Yes |
| Power Supply | AC100-240V 50/60Hz |
| Power Consumption (On Mode, W) | 187 |
| Power Consumption (Sleep Mode, W) | 0.5 |
| Set Dimension (WxHxD, mm) | 1456.8 x 831.9 x 28.5 |
| Package Dimension (WxHxD, mm) | 1616 x 945 x 164 |
| Set Weight (kg) | 21.5 |
| Package Weight | 28.0 |
| Temperature | 0℃~ 40 ℃ |
| Humidity | 10 ~ 80%, non-condensing |
| VESA Mount (mm) | 400 x 300 |
| Bezel Width (mm) | 11.5mm (even) |
| Frame Material | Non-Glossy |
| Mount | WMN-B50SC |
| Stand | STN-L6585C |
| OS Version | Tizen 7.0 |
| Flash Memory Size | 16GB |
| Energy Efficiency Class | A |
| EMC | Class B |
| Safety | 60950-1, 62368-1 |
