Teltonika TSW304 4-port Compact Unmanaged Switch with Integrated DIN Rail Mount, 4 x Gigabit Ethernet, Speeds Up to 1000 Mbps, 2 Pin Industrial Power Socket, IP30 Rated, Black | TSW304
Teltonika TSW304 4-port Compact Unmanaged Switch with Integrated DIN Rail Mount, 4 x Gigabit Ethernet, Speeds Up to 1000 Mbps, 2 Pin Industrial Power Socket, IP30 Rated, Black | TSW304 - Image 2
Teltonika TSW304 4-port Compact Unmanaged Switch with Integrated DIN Rail Mount, 4 x Gigabit Ethernet, Speeds Up to 1000 Mbps, 2 Pin Industrial Power Socket, IP30 Rated, Black | TSW304 - Image 3
Teltonika TSW304 4-port Compact Unmanaged Switch with Integrated DIN Rail Mount, 4 x Gigabit Ethernet, Speeds Up to 1000 Mbps, 2 Pin Industrial Power Socket, IP30 Rated, Black | TSW304 - Image 4

Teltonika TSW304 4-port Compact Unmanaged Switch with Integrated DIN Rail Mount, 4 x Gigabit Ethernet, Speeds Up to 1000 Mbps, 2 Pin Industrial Power Socket, IP30 Rated, Black | TSW304

  • Ethernet: 4 x RJ45 ports, 10/100/1000 Mbps
  • Bandwidth (Non-blocking): 8 Gbps
  • Packet buffer: 128 KB
  • MAC address table size: 2K entries

575.94 د.إ

TSW304 is Teltonika Networks’ first unmanaged switch with an integrated, built-in DIN rail mount. Equipped with four Gigabit Ethernet ports supporting the IEEE 802.3, IEEE 802.3u, and 802.3az Ethernet standards. Designed with easy installation in mind, the TSW304 features a compact size with a shock-resistant casing to go along with its integrated DIN mount. 10/100/1000 Mbps Ethernet ports for economical, high-bandwidth solutions to provide reliable data throughput. 2-pin industrial power socket and wide range of supported power supply voltages (7-57 VDC and 9-40 VAC). DIN RAIL Built-in, integrated DIN mounting COMPACT 102 x 25 x 81.5 mm GIGABIT ETHERNET 4 x Gigabit Ethernet with speeds of up to 1000 Mbps 7

SKU: SKU-7EBD0AFC Category: Brand:

Technical Specifications

Ethernet 4 x RJ45 ports, 10/100/1000 Mbps
Bandwidth (Non-blocking) 8 Gbps
Packet buffer 128 KB
MAC address table size 2K entries
Jumbo frame support 9216 bytes
Connector 2-pin power socket
Input voltage range 7 – 57 VDC; 9 – 40 VAC
PoE (passive) Passive PoE. Possibility to power up through first LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
Power consumption Idle: 0.26 W / Max: 1.44 W
Status LEDs 1 x Power LED, 8 x LAN status LEDs
Power 1 x 2-pin power socket
Ground 1 x Grounding screw
Casing material Anodized aluminum housing and panels
Dimensions (W x H x D) 102x25x81.5 mm
Weight 210 g
Mounting options Integrated DIN rail bracket, flat surface placement
Operating temperature -40 C to 75 C
Operating humidity 10 % to 90 % non-condensing
Ingress Protection Rating IP30
Regulatory CE, REACH, RoHS, WEEE
TSW304 UKCA, FCC, IC, CB, RCM
