ESC8000-E11 4U dual-socket GPU server powered by 5th Gen Intel Xeon Scalable processors that supports eight dual-slot GPUs, 32 DIMM, 11 PCIe 5.0, dual NVMe, four 3000W Titanium power supplies, OCP 3.0, and ASUS ASMB11-iKVM Key Features Powerful performance: Powered by 5th Gen Intel® Xeon® Scalable processors unleash up to 21%-greater general-purpose performance per watt, significantly improving AI inference and training AI and HPC workloads ready: Up to eight dual-slot active or passive GPUs, NVIDIA NVLink® bridge, and NVIDIA Bluefield DPU support to enable performance scaling Power-efficient system design: Independent CPU and GPU airflow tunnels for thermal optimization and support for up to four 3000W Titanium redundant power supplies for uninterrupted operation Cooling solutions: Enhanced air cooling based on CPU TDP for versatile workloads Scale-up storage and expansion design: A total of eight bays in combination of Tri-Mode NVMe/SATA/SAS drives on the front panel and 11 PCIe 5.0 slots for higher ba
Servers
Asus 4U Dual-Socket GPU Server, Dual 2x Intel Xeon Platinum 8580 300M Cache, 2 GHz Max 4 GHz, Gpu RTX A5000 24GB, 512 GB Ram , 8x 1 92TB SATA SSD / 2x 480GB SSD STA ASMB11-iKVM ESC8000-E11
- Processor / System Bus: 2 x Socket
- Memory: Total Slots: 32 (8 channel per CPU, 16 DIMM per CPU)
- Expansion Slots: 8 x PCIe slots (Gen5 x16 link, FH,FL) for dual-slot GPU cards
- Storage: Drive Bays: 8 x 3.5"/2.5" Front Hot-swap Storage Bays
162,279.96 د.إ
Technical Specifications
| Processor / System Bus | 2 x Socket |
| Memory | Total Slots: 32 (8 channel per CPU, 16 DIMM per CPU) |
| Expansion Slots | 8 x PCIe slots (Gen5 x16 link, FH,FL) for dual-slot GPU cards |
| Storage | Drive Bays: 8 x 3.5"/2.5" Front Hot-swap Storage Bays |
| Networking | 2 x 10GbE LAN ports (RJ45, X710-AT2) or 2 x Gigabit LAN ports (RJ45, I350-AM2) |
| Multi-GPU Support | Please find the latest GPU support from https://servers.asus.com/support/gpu |
| Front I/O Ports | 2 x USB 3.2 Gen1 ports |
| Rear I/O Ports | 1 x COM port |
| Switch/LED | Front: 1 x Power Button w/LED |
| OS Support | Please find the latest OS support from https://servers.asus.com/support/os |
| Management Solution | ASUS Control Center Enterprise (in-band) |
| Regulatory Compliance | BSMI, CB, CE, FCC(Class A), RCM |
| Dimensions | 800mm x 440mm x 174.5 mm |
| Form Factor | 4U |
| Weight | Net Weight: 27 Kg. |
| Power Supply | 2+2 Redundant 2600W/3000W 80 PLUS Titanium Power Supply |
| Environment | Operation temperature: 10℃ ~ 35℃ |
