airMAX AM-M-V5G-TI Titanium Sector Antenna The Ubiquiti Networks airMAX AM-M-V5G-TI Titanium Sector Advanced RF Isolation Variable Beamwidth Antenna is designed to work seamlessly with the Rocket M5, Rocket M5 GPS, and Rocket M5 Titanium radios. In fact, there’s even an integrated Rocket radio mount built right into the back of the antenna. The antenna also features a custom-designed Protective Shroud that helps to shield your Rocket radio from the elements. It has a 5.4 to 5.85 GHz frequency range and 1.7:1 maximum VSWR. The airMAX Titanium Sector is highlighted by its variable beamwidth configuration, which enhances scalability and streamlines inventory. The configuration setting options include 60°, 90°, and 120°. The antenna is outfitted with dual weatherproof RP-SMA connectors and it can withstand wind speeds up to 125 mph. The antenna is highly resista
Antennas
Ubiquiti Networks airMAX AM-M-V5G-TI Titanium Sector Advanced RF Isolation Variable Beamwidth Antenna, Frequency Range Is 5.4 to 5.85 Hz, Custom-Designed Protective Shroud | AM-M-V5G-TI
- Dimensions: 385 x 149 x 76 mm
- Weight: 3.25 kg (with Brackets)
- Frequency Range: 5.45 – 5.85 GHz
- Beamwidth Angles: 60°/ 90°/ 120°
539.74 د.إ
Technical Specifications
| Dimensions | 385 x 149 x 76 mm |
| Weight | 3.25 kg (with Brackets) |
| Frequency Range | 5.45 – 5.85 GHz |
| Beamwidth Angles | 60°/ 90°/ 120° |
| Gain (Beamwidth Dependent) | 17 dBi @ 60°16 dBi @ 90°15 dBi @ 120° |
| Elevation Beamwidth | 4° |
| Electrical Downtilt | 3° |
| Wind Survivability | 125 mph |
| Wind Loading | 15 lbf @ 100 mph |
| Polarization | Dual Linear |
| Cross-Pol Isolation | 25 dB Typical |
| Front-to-Back Ratio | 35 dB Typical |
| Max. VSWR | 1.7:1 |
| RF Connectors | 2 RP-SMA Connectors (Weatherproof ) |
