  • Dimensions: 353 x 46 x 34.4 mm (13.9 x 1.81 x 1.35")
  • Weight: 152 g (5.36 oz) with Antennas
  • Networking Interface: 2×2 WiFi dual band / Ethernet Gigabit
  • Ports: (2) 10/100/1000 Ethernet

342.86 د.إ

UAP-AC-M AC Mesh High-performance, outdoor, 2×2 MIMO, 802.11AC dual-band access point. With the indoor/outdoor UAP-AC-M-US UniFi AC Mesh Wide-Area Dual-Band Access Point from Ubiquiti Networks , users benefit from a wide coverage area reaching up to 600′ along with enhanced data transfer rates of up to 867 Mb/s on the 5 GHz frequency. These enhanced data rates and coverage capabilities are supported by a 2×2 MIMO internal antenna configuration supporting multiple data paths for a more efficient end-user network connection. Installation of the UAP-AC-M-US is simple, as it comes 802.3af PoE-compliant and includes a wall/pole/fast-mount kit. Once installed, users can take advantage of 802.11ac Wi-Fi access with speeds of up to 867 Mb/s in the 5 GHz radio band, and up to 300 Mb/s in the 2.4 GHz radio band. Key Features

SKU: SKU-A8F9A849 Category: Brand:

Technical Specifications

Dimensions 353 x 46 x 34.4 mm (13.9 x 1.81 x 1.35")
Weight 152 g (5.36 oz) with Antennas
Networking Interface 2×2 WiFi dual band / Ethernet Gigabit
Ports (2) 10/100/1000 Ethernet
Buttons Reset
Antennas 2 Dualband antennas
Wi-Fi Standards 802.11a/b/g/n/ac
Power Method 24V Passive PoE (Pairs 4, 5+; 7, 8 Return);802.3af Alternative A (Pairs 1, 2+; 3, 6 Return)(Supported Voltage Range: 44 to 57VDC)
Power Supply 24V, 0.5A Gigabit PoE Adapter*
Maximum Power Consumption 8.5W
Max TX Power 20 dBm
BSSID Up to Four per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Certifications CE, FCC, IC
Mounting Wall/Pole/Fast-Mount (Kits Included)
Operating Temperature -30 to 70° C (-22 to 158° F)
Operating Humidity 5 to 95% Noncondensing
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffic Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 100+
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11ac 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
