UBIQUITI NSM5 5.0GHz Nano MIMO 150+Mbps RANGE 15+Km , Indoor/Outdoor CPE, 2 x 10/100 Ethernet PoE Ports, Works airMAX , White | NSM5

  • Dimensions: 294 x 31 x 80 mm(11.57 x 1.22 x 3.15")
  • Weight: 400 g (14.11 oz)
  • Power Supply (PoE): 24V, 0.5A
  • Max. Power Consumption: 8W

279.53 د.إ

Featuring a panel antenna and dual-polarity performance, the NanoStation®M is ideal for Point-to-MultiPoint (PtMP) applications requiring high-performance CPE devices with a sleek form factor. Key Features 5 GHz Operating Frequency 2 x 10/100 Ethernet PoE Ports Indoor/Outdoor CPE Works airMAX Antennas SKU: SKU-73643B4E Category: Brand:

Technical Specifications

Dimensions 294 x 31 x 80 mm(11.57 x 1.22 x 3.15")
Weight 400 g (14.11 oz)
Power Supply (PoE) 24V, 0.5A
Max. Power Consumption 8W
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Operating FrequencyWorldwideUSAUSA DFS 5170-5875 MHz5725-5850 MHz5250-5850 Mhz
Gain 14.6-16.1 dBi
Networking Interface (2) 10/100 Ethernet Ports
Processor Specs Atheros MIPS 74Kc, 560 MHz
Memory 64 MB DDR2, 8 MB Flash
Frequency 5 GHz
Cross-pol Isolation 22 dB Minimum
Max. VSWR 1.6:1
Beamwidth 43° (H-pol) / 41° (V-pol) / 15° (Elevation)
Polarization Dual Linear
Enclosure Outdoor UV Stabilized Plastic
Mounting Pole-Mount (Kit Included)
Operating Temperature -30 to 75° C (-22 to 167° F)
Operating Humidity 5 to 95% Noncondensing
Wireless Approvals FCC Part 15.247, IC RS210, CE
RoHS Compliance Yes
Shock & Vibration ETSI300-019-1.4
